LW186 laboratory small capacity 2phase decanter centrifuge low noise and vibration

LW186 laboratory small capacity 2phase decanter centrifuge low noise and vibration

Product description

HUADING SEPERATOR has develop the lab decanter centrifuge with small capacity of 100-1000L/H, the small equipment need to take up very little space to install, it is a ideal equipment for the experimental phase before the industry mass production and some special department, such as collages and universities.

Decanter centrifuge is a horizontal centrifuge with automatic continuous feeding discharging. The settling speed of bowl and screw is determined by the feed material condition, such as particle size, particle shape, the difference in density between solids and liquids as well as their viscosity. The speed of bowl and screw will be adjusted by the VFD through the double motors speed adjustment. The decanter centrifuge adapt double motor driving, the bowl and screw are driven by two variable frequency motors and two frequency converters. This type decanter centrifuge has the advantages to treat the materials without a constant solid content and those having strict requirements for the water content of discharged solids. The decanter centrifuge can be used to treat the feed with solid phase particles size of 0.005-3mm and solid content of 0.5-50%.

Product features

1. All the parts contact with the feed material are made by high grade stainless steel, such as double duplex stainless steel
2. The operation is control by PLC module, can release intelligent automatic operation , continuous and automatic feeding and discharging
3. Two motor and two frequency inverter drive system, realize differential speed of bowl and screw stepless regulation and energy return
4. The surface of screw and discharging port is hardened, such as hard alloy and ceramic, better protection for the parts prone to wear and tear, for a long service life
5. Multiple safety protection: bowl speed and differential speed detection, over-vibration protection, motor overload and overheat protection, bearing temperature monitoring, conveyor torque protection and gas-tight explosion-proof protection.

Product parameter

Typical application

• TCM preparation
• Pharmaceutical intermediates
• Plant extraction
• Blood products
• Benzoic acid
• Vegetable juice
• Ammonium chloride
• ...

Company introduction

Huading Separator has been at the forefront in the field of centrifugal separation technology for more than 60 years, established in 1954, is the leader in mechanical separating technology in China. The machines produced by Huading Separator are used in a wide range of areas – in the beverage and dairy industries, in recovering and processing oils and fats, as well as in chemicals, pharmaceuticals, biotechnology and starch technology. Other applications include marine engineering, energy, oil fields, water treatment, such as waste water treatment, sludge dewatering, etc

Why choose us

1. 60+ years experience in the design and manufacturing of separator and decanter
2. 200+ workers, 30+ technical team and after-sales team
3. Complete manufacturing facilities and test equipment, 90% parts of the machines are made in HUADING own factory
4. Main outsourcing parts are world famous, such as SKF, SIEMENS, ABB
5. Good after-sale service, provide on-site service,help to train staff how to operate and maintain machines

FAQ

1.Who you are?
Huading Machinery are separators and decanters manufacturer from 1954, we have more than 60 years experience in the design and manufacturing of centrifugal separation equipment. Huading separators and decanters are widely applied in industry of food, beverage,pharmaceutical.chemical,marine,oilfield,energy,mining,mechanical engineering and waste water treatment etc.

2.How do you guarantee the quality?
We are a professional manufacturer with experience of more than 60 years. We have the most advanced equipment and first-class workers. Each of our processing procedures is strictly inspected and has the test report. We also accept FAT testing from customers.

3.How long is the warranty period?
One year after the machine arrives customer site

4. Do you have technicians for installation, commissioning and training?
After-sales service is available, we can send our technicians to customer site for installation,commissioning and training, also can guide online through video

5.What's the payment terms you can accept?
Generally T/T, L/C at sight
