SKF Decanter Centrifuge Separators SUS 316 Water Treatment Centrifuge

New solid liquid separation equipment decanter centrifuge for water treatment

Product description

Water resources are key resources for human to survive. Nowadays, human activities has led to severe destruction of biological environments and serious water pollution. Therefore, the protection of water resources and administration of water pollution have become a matter of greatest concern in modern society.

The decanter centrifuges from HUADING SEPARATOR has been widely applied for water and waste water treatment, the equipment enable us to bring forward economical, efficient and sustainable treatment solutions ranging from drinking water treatment to urban and industrial waste water treatment according to different user demands

The decanter centrifuge is a kind of machinery that carries out continuous separation of materials of density difference in suspensions by using the centrifugal sedimentation principle.

The basic principle is: the bowl and feeding screw make high-speed rotation with a certain differential speed between them, the materials are injected continuously by the feed tube into the inner cylinder of the spiral material pusher, and then enter the bowl after acceleration. Under the action of centrifugal force field, the heavier solids will deposit on the bowl walls and form residue layers. The spiral material pusher will continuously push the deposited solids to the taper end of the bowl and discharge them out of the machine from the residue outlet after dehydration in the drying area

Product features

1. All the parts contact with the feed material are made by high grade stainless steel, such as double duplex stainless steel
2. The operation is control by PLC module, can release intelligent automatic operation , continuous and automatic feeding and discharging
3. Two motor and two frequency inverter drive system, realize differential speed of bowl and screw stepless regulation and energy return
4. The surface of screw and discharging port is hardened, such as hard alloy and ceramic, better protection for the parts prone to wear and tear, for a long service life
5. Multiple safety protection: bowl speed and differential speed detection, over-vibration protection, motor overload and overheat protection, bearing temperature monitoring, conveyor torque protection and gas-tight explosion-proof protection

Product parameter

Application fields

• Drinking water treatment
• Sludge dewatering
• Sewage concentration
• Corporate waste water treatment
• Municipal waste water treatment
• Process water treatment

Company introduction

Huading Separator has been at the forefront in the field of centrifugal separation technology for more than 60 years, established in 1954, is the leader in mechanical separating technology in China. The machines produced by Huading Separator are used in a wide range of areas – in the beverage and dairy industries, in recovering and processing oils and fats, as well as in chemicals, pharmaceuticals, biotechnology and starch technology. Other applications include marine engineering, energy, oil fields, water treatment, such as waste water treatment, sludge dewatering, etc

FAQ

1.Who you are?
Huading Machinery are separators and decanters manufacturer from 1954, we have more than 60 years experience in the design and manufacturing of centrifugal separation equipment. Huading separators and decanters are widely applied in industry of food, beverage,pharmaceutical.chemical,marine,oilfield,energy,mining,mechanical engineering and waste water treatment etc.

2.How do you guarantee the quality?
We are a professional manufacturer with experience of more than 60 years. We have the most advanced equipment and first-class workers. Each of our processing procedures is strictly inspected and has the test report. We also accept FAT testing from customers.

3.How long is the warranty period?
One year after the machine arrives customer site

4. Do you have technicians for installation, commissioning and training?
After-sales service is available, we can send our technicians to customer site for installation,commissioning and training, also can guide online through video

5.What's the payment terms you can accept?
Generally T/T, L/C at sight
