Huading 2&3 phase horizontal screw discharging decanter centrifuge PLC control automatic operation

Huading 2&3 phase horizontal screw discharging decanter centrifuge PLC control automatic operation

Product description

Decanter centrifuge is a mechanical equipment which utilize the principle of centrifugal and sedimentation and can carry out continual separate the suspend liquid with density difference.
The decanter centrifuge can be used to clarify, dehydrate and classify the suspensions with 0.002-3 mm solid phase particles and thickness range at 0.5~50%.
According to feeding liquid feature, product can be divided into two-phase and three phase decanter centrifuge. The decanter centrifuge adopt double motor driving, the bowl and screw are driven by two variable frequency motors and two frequency converters. By the double motors driving, the differential speed between the bowl and screw can be adjusted through simple adjustment of the rotation speed of the motors. It can be perfect suitable for the treatment of the material without a constant solid content and those having strict requirements for the water content of discharged solids.

It is suitable for separating different feed under different process condition, and widely use in pharmaceutical, food, chemical, light industry, environmental protection industry etc

Technical features

1. All contact with the material are made of high quality stainless steel, or duplex stainless steel.
2. In order to ensure a high dryness cake, specially designed bowl and spirals are pressed against the dewatered cake at the conical end of the bowl in a high-pressure, two way manner to minimize the moisture content of the cake
3. The machine uses double motor double frequency conversion, and with multi-stage planetary gear drive. The difference in speed between the bowl and the screw can be automatically adjusted by the control system in real time based on the characteristics of the raw materials and the user’s requirements, ensuring consistency of the high-dry mud cake, even in the case of changing raw materials. At the same time unique DC bus-powered design, to ensure a strong spiral torque, while greatly reducing power consumption. In addition to include full hydraulic drive, including a variety of drive options for the user to choose.
4. A wide range of wear protection are available, including welded hard facing or spray coating, ceramic port, zn carbide tiles, chilled hard metal portcastings, etc. All wear protection elements, except welded hard facings or spray coatings, are field replaceable.

Typical application

• Plant extraction
• TCM preparation
• Pharmaceutical intermediates
• Starch
• Fish processing
• Soy milk
• Fruit juice
• Beer yeast and lees
• Diatomite
• Benzoic acid
• Kitchen waste
• Waste water treatment
• Well sludge
• ...

Company introduction

Huading Separator has been at the forefront in the field of centrifugal separation technology for more than 60 years, established in 1954, is the leader in mechanical separating technology in China. The machines produced by Huading Separator are used in a wide range of areas – in the beverage and dairy industries, in recovering and processing oils and fats, as well as in chemicals, pharmaceuticals, biotechnology and starch technology. Other applications include marine engineering, energy, oil fields, water treatment, such as waste water treatment, sludge dewatering, etc

FAQ

1.Who you are?
Huading Machinery are separators and decanters manufacturer from 1954, we have more than 60 years experience in the design and manufacturing of centrifugal separation equipment. Huading separators and decanters are widely applied in industry of food, beverage,pharmaceutical.chemical,marine,oilfield,energy,mining,mechanical engineering and waste water treatment etc.

2.How do you guarantee the quality?
We are a professional manufacturer with experience of more than 60 years. We have the most advanced equipment and first-class workers. Each of our processing procedures is strictly inspected and has the test report. We also accept FAT testing from customers.

3.How long is the warranty period?
One year after the machine arrives customer site

4. Do you have technicians for installation, commissioning and training?
After-sales service is available, we can send our technicians to customer site for installation,commissioning and training, also can guide online through video

5.What's the payment terms you can accept?
Generally T/T, L/C at sight
